- Stock: In Stock
- Model: WS12L-2N430
- Weight: 0.26kg
2. Shipping options include DHL, UPS, FedEx, and EMS.
3. Estimated delivery time for express shipping via DHL, UPS, FedEx, or EMS generally ranges from 3 to 10 business days, depending on the destination country.
4. Please verify your address thoroughly when placing your order.
5. Important for buyers: You are responsible for any tariffs on accessories. To potentially avoid these tariffs, you may choose EMS express shipping.
6. The shipping service is responsible for any accidents, delays, or other issues that may arise.
Returns:
We offer a 14-day return policy. If you wish to return an item, please contact us within 14 days and ensure that the package remains unopened. The buyer is responsible for the shipping costs for both the return and the initial delivery, as well as any applicable customs fees. Once we receive and inspect the product, we will process your refund within 24 hours.
For any quality issues that arise during normal use within the warranty period, we will repair the item free of charge. The buyer is responsible for the return shipping cost, while our company will cover the cost of re-shipping the repaired item.
Product Description:
Laser class 2
? Adjustable focus and sensitivity
? 90° rotatable M12 plug
Specifications:
Scanning range, max. typical | 80 m |
10 m | |
Recommended operating range | 80 m |
10 m | |
Focus adjustable | 300 mm ...∞ |
Fixed parallel light beam | |
Light source1) | Laser 650 nm, pulsed |
Light spot diameter | 150 mm at 60 m |
| 1.0 mm at 1 m |
Supply voltage VS | 10...30 V DC2) |
Ripple3) | ≤ 5 VSS |
Current consumption4) | WS ≤ 45 mA, WE ≤ 15 mA |
Switching outputs Q and Q | PNP |
NPN | |
Signal voltage HIGH | VS – < 2.9 V, VS |
Signal voltage LOW5) | Approx. 0 V, ≤ 1.5 V |
Output current IA max. | 100 mA |
Response time max.6) | Typ. 200 μs |
Max. switching frequency7) | 2500/s |
Input ”TE” system test | VS or open: sender active |
0 V: sender inactive | |
VDE protection class8) | ? |
Laser class | 2 (IEC 825-1; EN 60825-1:97) |
Enclosure rating | IP 67, IP 69K |
Circuit protection9) | A, B, C |
Ambient temperature TA | Operation – 10 °C...+ 50 °C |
Storage – 25 °C...+ 75 °C | |
Connection type | M12 plug, 4-pin |
Weight (WS + WE) | Approx. 260 g |
1) Average service life 50,000 h at TA = + 25 °C
2) Limit values
3) May not exceed or fall short of VS tolerances
4) Without load
5) At TA = + 25 °C and 100 mA output current
6) Signal transit time with resistive load
7) At light/dark ratio 1:1
8) Reference voltage 50 V DC
9) A = VS connections reverse-polarity protected
B = Outputs protected against short-circuiting
C = Interference pulse suppression
