FS-N11MN KEYENCE Fiber sensor NEW

Type

NEW IP66 Fiberoptic Amplifer, 1 output type

Cable/M8 connector

M8 connector *1

Main unit/expansion unit

Main unit

Model

NPN

FS-N15CN

PNP

FS-N15CP

Control output

1 output

Monitor output (1-5V)

—

External input

1 input

Light source LED

Red 4-element LED (wavelength 630 nm)

Response time

50 μs (HIGH SPEED)/250 μs(FINE)/500 μs(TURBO)/ 1 ms (SUPER) /4 ms (ULTRA)/16 ms (MEGA)

Output toggle

Light-ON/Dark-ON toggle

Timer function

Timer OFF/OFF delay/ON delay/One-shot

Control output

NPN output

NPN open collector 24 V or less; maximum 100 mA or less, residual voltage 1 V or less

PNP output

PNP open collector 24 V or less; maximum 100 mA or less, residual voltage 1 V or less

External input

Input time 2 ms (ON)/20 ms (OFF) or more, when selecting External calibration 25 ms (ON/OFF) or more

Expansion units

0 units (expansion not possible)

Protection circuit

Protection against reverse power connection, Output overcurrent, and Output surge

Number of interference prevention units

0 units (connection not possible)

Rating

Power voltage

12 to 24 V DC ± 10% ripple (P-P) 10% or less

NPN

Normal: 900 mW or less (36 mA max. at 24 V, 48 mA max. at 12 V) *2
Econ on (ALL): 800 mW or less (32 mA max. at 24 V, 39 mA max. at 12 V) *2
Eco full: 470 mW or less (19 mA max. at 24 V, 23 mA max. at 12 V)

PNP

Normal: 950 mW or less (39 mA max. at 24 V, 52 mA max. at 12 V) *2
Eco on (ALL): 850 mW or less (35 mA max. at 24 V, 44 mA max. at 12 V) *2
Eco full: 520 mW or less (21 mA max. at 24 V, 26 mA max. at 12 V)

Environmental
resistance

Operating ambient luminance

Incandescent lamp: 20,000 lux or less, sunlight: 30,000 lux or less

Operating ambient temperature

-20°C to +55°C -4°F to 131°F (no freezing)

Operating ambient humidity

35 to 85%RH (no condensation)

Vibration resistance

10 to 55 Hz compound amplitude 1.5 mm 0.06", 2 hours for each of X, Y, Z axis

Shock resistance

500 m/s2, 3 times for each of X, Y, Z axis

Enclosure rating

IP66 *3*4

Material

Case

Main unit: glass-reinforced PBT; Cover: Sulfonic resin

Adapter

Glass-reinforced PBT

Case Dimensions

H 31.0 mm × W 13.0 mm × L 94.0 mm H 1.22" x W 0.51" x L 3.70"

Weight

App. 30g
