- Stock: In Stock
- Model: E32-C31
- Weight: 0.05kg
2. Shipping options include DHL, UPS, FedEx, and EMS.
3. Estimated delivery time for express shipping via DHL, UPS, FedEx, or EMS generally ranges from 3 to 10 business days, depending on the destination country.
4. Please verify your address thoroughly when placing your order.
5. Important for buyers: You are responsible for any tariffs on accessories. To potentially avoid these tariffs, you may choose EMS express shipping.
6. The shipping service is responsible for any accidents, delays, or other issues that may arise.
Returns:
We offer a 14-day return policy. If you wish to return an item, please contact us within 14 days and ensure that the package remains unopened. The buyer is responsible for the shipping costs for both the return and the initial delivery, as well as any applicable customs fees. Once we receive and inspect the product, we will process your refund within 24 hours.
For any quality issues that arise during normal use within the warranty period, we will repair the item free of charge. The buyer is responsible for the return shipping cost, while our company will cover the cost of re-shipping the repaired item.
Product Description:
Diffuse-reflective , Coaxial/Small spot , M3 screw.
Specifications:
Product outline | M3 screw head coaxial reflective fiber |
Sensing method | Diffuse-reflective |
Shape | Screw-shaped Top view |
Fiber cable type | Standard |
Standard Length | 2m |
Minimum bending radius | R 25 mm Min. |
Free-cut | Possible |
Degree of protection | IEC60529: IP67 |
Differential distance | 20% max. of sensing distance |
Ambient temperature | Operating: -40 to 70 CEL |
Ambient humidity | Operating: 35 to 85 %RH |
Vibration resistance | 10 to 55 Hz1.5-mm double amplitude for 2 hours each in X, Y, and Z directions |
Shock resistance | 500m/s2 for 3 times each in X, Y, and Z directions |
Weight (packedstate) | Approx. 50 g |
Material (Sensing head) | SUS303 |
Material (Fiber sheath) | Plastic (combination of PVC, polyethylene, and polyolefin coating) |
Material (Fiber core) | Acrylic resin (PMMA) |
Material (Clamping nuts) | Brass nickel plating |
Material (Toothed washer) | Brass nickel plating |
Tensile strength | 9.8 N Max. |
Clamping torque | 0.78 N.m Max. |
Accessories | Fiber cutter(E39-F4), Attachment for thin fiber(E39-F9) |
