E3S-LS3N PCB Sensors NEW

Sensing method

Limited Reflective

Sensing distance

20 mm to 35 mm (White paper 80*80mm)

Light source

Red LED (660nm)

Power supply voltage

12 to 24 VDC -10% to 10% (ripple(p-p) :10% Max.)

Current consumption

25mA DC Max.

Control output (Output type)

NPN open collector output

Control output (Load current)

0 to 100 mA

Control output (Residual voltage)

(DC) 1 V Max. (Load current 100mA Max.)

Operation mode

Light-ON

Load power supply voltage

24 VDC Max.

Protective circuit

Surge suppressor

Output short-cut protection

Power supply reverse polarity protection

Mutual interference prevention

Response time

1 ms Max.

Ambient illuminance

Incandescent lamp:5000 lux Max.

Ambient temperature

Operating: -10 to 55 CEL

Storage: -25 to 70 CEL

(with no icing or condensation)

Ambient humidity

Operating: 35 to 85 %RH

Storage: 35 to 95 %RH

(with no condensation)

Insulation resistance

20 M OHM Min. at 500 VDC between charged parts and the case

Dielectric strength

1000 VAC at 50/60 Hz for 1 minute between charged parts and the case

Vibration resistance

10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions

Shock resistance

500m/s2 for 3 times each in X, Y, and Z directions

Degree of protection

IEC60529: IP40

Applicable standard (EC Directive (Low Voltage Directive))

EN60947-5-2

Applicable standard (EC Directive (EMC Directive))

EMI: EN60947-5-2

Emission Enclosure: EN55011 Group 1 class A

EMS: EN60947-5-2

Immunity ESD: IEC61000-4-2

Immunity RF-interference: IEC61000-4-3

Immunity Burst: IEC61000-4-4

CE marking: Equipped

Connection method

Pre-wired models (Cable length: 2 m)

Indicator

Operation indicator(orange)

Weight (packed state)

approx. 80 g

Tightening torque

0.54 N.m Max. (with M3 screw)

Material (case)

ABS

Material (lens)

Methacrylate resin

Accessories

Instruction manual, M3 screw
