E3HT-DS3E1 Photoelectric Sensors NEW

Sensing method

 Through-beam

 Diffuse-reflective

 Through-beam

 Diffuse-reflective

 Model

 E3HT-1E?

 E3HT-DS3E?

 E3HC-1E?

 E3HC-DS3E?

 Sensing distance

 1 m

 35 mm (White paper 30 × 30 mm)

 1 m

 35 mm (White paper 30 × 30 mm)

 Standard sensing object

 Opaque, 6.25-mm dia. min.

 ---

 Opaque, 6.25-mm dia. min.

 ---

 Differential travel

 ---

 20% max. of sensing distance

 ---

 20% max. of sensing distance

 Directional angle

 Emitter/Receiver: 10 to 25° each

 ---

 Emitter/Receiver: 10 to 25° each

 ---

 Light source (wavelength)

 Infrared LED (950 nm)

 Infrared LED (940 nm)

 Infrared LED (950 nm)

 Infrared LED (940 nm)

 Power supply voltage

 12 to 24 VDC ±10%, ripple (p-p): 10% max.

 Current consumption

 Emitter: 25 mA max. Receiver: 15 mA max.

 30 mA max.

 Emitter: 25 mA max. Receiver: 15 mA max.

 30 mA max.

 Control output

 Load power supply voltage: 24 VDC max., Load current: 80 mA (Residual voltage: 1 V max.) NPN open collector output type Light-ON/Dark-ON (depends on model)

 Protection

 Reverse polarity protection, Output short-circuit protection

 Reverse polarity protection, Output short-circuit protection, Mutual interference prevention

 Reverse polarity protection, Output short-circuit protection

 Reverse polarity protection, Output short-circuit protection, Mutual interference prevention

 Response time

 Operate or reset: 5 ms max. each

 Operate or reset: 3 ms max. each

 Operate or reset: 5 ms max. each

 Operate or reset: 3 ms max. each

 Ambient illuminance (Receiver side)

 Incandescent lamp: 3,000 lx, Sunlight 10,000 lx

 Ambient temperature

 Operating: −25 to 55°C, Storage: −30 to 70°C (with no icing or condensation)

 Ambient humidity

 Operating: 35% to 85%, Storage: 35% to 95% (with no condensation)

 Insulation resistance

 20 MΩ min. at 500 VDC

 Dielectric strength

 500 VAC at 50/60 Hz for 1 minute

 Vibration resistance

 Destruction: 10 to 55 Hz, 1.5-mm double amplitude for 2 hours each in X, Y, and Z directions

 Shock resistance

 Destruction: 500 m/s2 for 3 times each in X, Y, and Z directions

 Degree of protection

 IEC IP66

 Connection method

 Pre-wired models (standard length: 2 m)

 Weight (packed state)

 Approx. 130 g

 Approx. 80 g

 Approx. 110 g

 Approx. 75 g

 Mate-rial Case

 Brass

 Stainless steel (SUS304)

 Mate-rial Lens

 Methacrylic resin

 Mate-rial Mounting Brackets

 ---

 Stainless steel (SUS304)

 Accessories

 Instruction sheet

 Mounting bracket (with screws), Instruction sheet
