AP-C33W KEYENCE Pressure sensor NEW

Product Description:

Self-contained Pressure Sensors

• 11-mm large, two-color LED display

• Choose from four different pressure units

• Fast response time of 2.5 ms

• Repeatability of ± 0.2% of F.S.

World's Most Compact Model with Maximum Character Height

The world's most compact size with a width of 30 mm and height of 25 mm and the largest character height (11 mm) in this class. Furthermore, the AP-C30K Series incorporates a very easy-to-see 2-color LED display.

*Actual size if screen resolution = 1024x768

Unit conversion function

The pressure can be displayed in any of four pressure units enabling it to be used worldwide

High Resolution

10x Area Focus Function

Based on the set reference pressure, the detected pressure can be precisely displayed within a ±20% pressure range. The AP-C30K Series ensures a resolution of 0.01 kPa*, which is the highest in this class. Although the AP-C30K Series is of mono-block construction, highly precise pressure detection is possible. The zero-shift function can be used as well. * When the AP-C31K is in focus mode.

All-in-one I/O Function

Independent 2-point output, analog monitor output, and zero-shift input are incorporated as standard functions. There is no need to prepare a number of sensors and select the best one among them properly according to the application.

* Either analog output or zero-shift input is selectable.

A Lineup of Multi-range Models Each Playing Three Roles

A new lineup of multi-range models is available, each of which supports a number of applications. By making setting changes, each model can be used as a negative pressure model, positive pressure model, or compound pressure model. Therefore, there is no need to keep a variety of models in stock.
