- Stock: In Stock
- Model: TCC-82
- Weight: 0.10kg
2. Shipping options include DHL, UPS, FedEx, and EMS.
3. Estimated delivery time for express shipping via DHL, UPS, FedEx, or EMS generally ranges from 3 to 10 business days, depending on the destination country.
4. Please verify your address thoroughly when placing your order.
5. Important for buyers: You are responsible for any tariffs on accessories. To potentially avoid these tariffs, you may choose EMS express shipping.
6. The shipping service is responsible for any accidents, delays, or other issues that may arise.
Returns:
We offer a 14-day return policy. If you wish to return an item, please contact us within 14 days and ensure that the package remains unopened. The buyer is responsible for the shipping costs for both the return and the initial delivery, as well as any applicable customs fees. Once we receive and inspect the product, we will process your refund within 24 hours.
For any quality issues that arise during normal use within the warranty period, we will repair the item free of charge. The buyer is responsible for the return shipping cost, while our company will cover the cost of re-shipping the repaired item.
If you need more than 10pcs and want to get better wholesale price, please feel free to contact us by following:
email:[email protected]
Tel:0086-574- 88333153
We will quote you our best price to you in 24hours.
Features and Benefits
4 channels of 4 KV RMS isolation for 1 minute
External power source supported but not required
15 KV serial ESD protection
Automatic baudrate detection
Compact size
Introduction
The TCC-82 provides full electrical isolation for bi-directional serial communication between two RS-232 devices in a compact, industrial grade package. Both sides of an RS-232 connection are isolated optically to provide perfect protection against lightning surges, accidental high voltage shorts, and ground loops. The built-in, wide range isolators are tested to ensure that they can withstand more than 4 KV rms input to output for 1 minute. This means that the TCC-82 not only meets the requirements of general serial data communications, but also the high standards required by industrial automation and medical applications. The TCC-82 protects the TxD and RxD data lines, and also protects the RTS and CTS handshake lines for a total of 4 isolated channels to provide complete protection of your RS-232 applications.
• Serial Communication | |
Connectors | DB9 male and DB9 female |
Baudrate | 50 bps to 921.6 Kbps |
Signals | RS-232: TxD, RxD, RTS, CTS, GND |
ESD Protection | 15 KV for all signals |
Optical Isolation | 4 KV for 1 minute |
• Physical Characteristics | |
Housing | ABS |
Dimensions | 42 x 80 x 23.6 mm (1.65 x 3.15 x 0.93 in) |
Weight | 60 ± 5 g |
• Environmental Limits | |
Operating Temperature | 0 to 60°C (32 to 140°F) |
Storage Temperature | -20 to 75°C (-4 to 167°F) |
Ambient Relative Humidity | 5 to 95% (non-condensing) |
• Power Requirements | |
Source of Input Power | RS-232 port (TxD, RTS, DTR) or power input jack |
Input Voltage | 5 to 12 VDC |
Power Consumption | 20 mA @ 5 V |
• Standards and Certifications | |
Safety | UL 60950-1 |
EMC | CE, FCC |
EMI | FCC Part 15 Subpart B Class B |
EMS | EN 61000-4-2 (ESD) Level 2, |
Green Product | RoHS, CRoHS, WEEE |
• MTBF (mean time between failures) | |
Time | 959,780 hrs |
Database | MIL-HDBK-217F |
