AB1216 RESIONA KVM Switch Business Series 16-port PS/2 interface

If you need more than 10pcs and want to get better wholesale price, please feel free to contact us by following:
email:[email protected]
Tel:0086-574- 88333153
We will quote you our best price to you in 24hours.

Product Features:

* 8/16 KVM switch

* Support a local control terminal

* Support Microsoft Windows, Netware Unix and Linux

* Support iMAC, Power MAC and Sun Micro Systems through the USB interface

* Without having to install software: simply select the computer through the on-screen menu, button or hotkey

* Offers a variety of hot key combination (Scroll-Lock / Caps-Lock / Num-Lock / Alt / Ctrl / Win), switch the computer port and other control functions, the hotkey function can be used in a variety of types of keyboard can also prevent hotkey to repeat the question

* Support are two levels of password security protection

* ACL security features (allows control list), you can store up to 8 independent control list

* Hotplugged: You do not need to shut down the KVM switch or computer, you can add or remove the connected computer

* Support display Plug and Play

* When switching computer keyboard state Reply

* Supports cascading of up to 8 layers

Packing:

* 1 x KVM Switch

* 1 x CD CD-ROM User's Manual

* 1 x AC-DC adapter

* 1 x rack accessories

* 1 x DC2.5 revolution DB9 female wire

* 1 x warranty card

* 1 x certificate

* 1 x desiccant

Specifications:

Port connector VGA
8/16 of the number of ports
Control port type USB
Longest distance of 16 feet (5 meters)
(KVM switch - the host)
Image resolution (local control end) 1920X1440
Upgrade port DC2.5F
Cascade Connector DB15 (female)
Support cascaded to eight levels
Computer to select on-screen menus, hotkeys, buttons
The hotkey to provide a variety of hotkeys (Scroll-Lock/Caps-Lock/Num-Lock/AIt/Ctel/Win
Computer port lights each port two lights; ON the LINE (yellow), SATAION (red)
Security allows control list security features, can be stored for eight independent control of computer users
Multi-lingual on-screen menu languages ??(English, French, German, Spanish, Italian, Russian, Japanese and Simplified Chinese
Automatic scanning intervals of 5 to 99 seconds
Keyboard Wedge USB
Mouse Emulation USB
The maximum number of computers connected to up to 128 computers (16 models X8 layer)
Shell material Hulled
DC Power Supply 12V, 1A
Operating temperature 0 to 50 ° C
Storage temperature -20 ~ 60 ?
Humidity 0 to 80%, non-condensing
Bodies of 19-inch rack-mountable, 1U
Dimensions (mm) 444.5 x 190 x 44
