Function / Arbitrary Waveform Generator DG3101A

Function / Arbitrary Waveform Generator  DG3101A
Function / Arbitrary Waveform Generator  DG3101A
Function / Arbitrary Waveform Generator  DG3101A
Function / Arbitrary Waveform Generator  DG3101A
Function / Arbitrary Waveform Generator DG3101A
Features and Benefits1 Optional Digital Logic Output Module, mixed-signal output 2) direct digital f... Read More
$3,000.00
Ex Tax: $3,000.00
  • Stock: In Stock
  • Model: DG3101A
  • Weight: 5.00kg
1. We typically ship items within three business days after payment is received.
2. Shipping options include DHL, UPS, FedEx, and EMS.
3. Estimated delivery time for express shipping via DHL, UPS, FedEx, or EMS generally ranges from 3 to 10 business days, depending on the destination country.
4. Please verify your address thoroughly when placing your order.
5. Important for buyers: You are responsible for any tariffs on accessories. To potentially avoid these tariffs, you may choose EMS express shipping.
6. The shipping service is responsible for any accidents, delays, or other issues that may arise.

Returns:
We offer a 14-day return policy. If you wish to return an item, please contact us within 14 days and ensure that the package remains unopened. The buyer is responsible for the shipping costs for both the return and the initial delivery, as well as any applicable customs fees. Once we receive and inspect the product, we will process your refund within 24 hours.
For any quality issues that arise during normal use within the warranty period, we will repair the item free of charge. The buyer is responsible for the return shipping cost, while our company will cover the cost of re-shipping the repaired item.
We accept many payments,include Paypal,Bank Transfer etc
Tags: DG3101A

Features and Benefits

1 Optional Digital Logic Output Module, mixed-signal output

2) direct digital frequency synthesis (DDS)
3. 300 MSa / s sampling rate, 14 bits of vertical resolution, 1 Mpts waveform length
4. 3.8 "QVGA color LCD display
 5. 10 standard waveforms: sine, square, sawtooth, pulse, noise, rose, fell, Sinc wave, electrocardiogram wave, DC
 6 user-defined arbitrary waveform
 7. Rich modulation: AM (AM), frequency modulation (FM), phase modulation (PM), frequency shift keying (FSK), pulse-width modulation (PWM), sweep (SWEEP), Burst (BURST)

8. Rich input and output signals: Waveforms output, synchronous signal output, an external modulation source, an external 10MHz reference clock, external trigger input, the internal 10MHz clock output
 9. A variety of interfaces: USB Host & Device, RS-232, GPIB, LAN
10 built-in Ethernet interface to support the WEB remote control
11.USB Host slot, support USB storage drive
 12 with the DS1000 series oscilloscopes seamless connectivity, direct access storage oscilloscope waveforms and non-destructive to reproduce
13 language user interface, built-in help system
 14 is equipped with a powerful arbitrary waveform editing software UltraWa





Model



DG3121A

DG3101A

DG3061A

Maximum output frequency



120 MHz

100 MHz

60 MHz

Output Channels



1

Sampling rate



300 MSa/s

Any wave length



2 pts – 1 Mpts

Frequency resolution



1 μHz

Amplitude range



10 mVpp ~ 10 Vpp?50 Ω??20 mV ~ 20 Vpp????

Vertical resolution



14 bits

Standard Interface



USB Host & Device?RS-232?GPIB(IEEE-488)?LAN

Optional Interface





Product category



Desktop Function / Arbitrary Waveform Generator
