MA-4AD2DA XINJE PLC MA Original Brand New
Features:
MA-4AD2DA MA series modules 4 channels analog input 2 channels analog output PID control function
MA series modules can connect with PLC, PLC&HMI integrator, HMI and other devices via RS485 and Modbus protocol. It has various types, can meet all your requirements about analog and digital control.
Characters:
4 channels analog input
2 channels analog output
12 bits high precision input
current/voltage mode selectable
voltage mode output/input range: DC 0~5V, 0~10V
current mode output/input range:DC 0~20mA, 4~20mA
PID control function for analog input
self-study PID parameters
DC 24V power supply
Support Modbus-RTU protocol
RS485 port, can connect with PLC, HMI and other devices
Can extend 16 this kind of modules at most
Specifications:
Item | Analog input ( 4AD ) | Analog output ( 2DA ) | ||
| Voltage input | Current input | Voltage output | Current output |
Analog input range | 0~5V,0~10V | 0~20mA,4~20mA | - | |
Max input range | DC±18V | 0~40mA | - | |
Analog output range | - | 0~5V,0~10V, ( exterior load resistor 2KΩ~1MΩ) | 0~20mA,4~20mA (exterior load resistor less than 500Ω) | |
Digital input range | - | 10 bits binary number (0~1023) | ||
Digital output range | 12 bits binary number (0~4095) | - | ||
Resolution | 1/4095(12Bit) | 1/1023(10Bit) | ||
PID output value | 0~K4095 |
| ||
Integrated precision | 0.8% | |||
Conversion speed | 20ms/1 channel | 3ms/1 channel | ||
Power supply for analog quantity | DC24V±10%,100mA | |||
Installation | Use M3 screw or fix on the DIN46277 ( width 35mm ) rail | |||
Profile dimension | 63mm×102mm×73.3mm | |||
Product appearance and size chart
