Omron PLC CJ1W-OD201
Product Description:
1. High-speed output models are available, meeting versatile applications.
2. ON Response Time: 15μs, OFF Response Time: 80μs
3. Output Units are available with any of three output types: relay contact outputs, triac outputs, or transistor outputs.
4. For transistor outputs, select from sinking outputs or sourcing outputs.
5. Output Units with load short-circuit protection are also available. *1
6. Select the best interface for each application: Fujitsu connectors or MIL connectors. *2
7. A wide variety of Connector-Terminal Block Conversion Units are available to allow you to easily wire external output devices.
*1.The following Units have load short-circuit protection: CJ1W-OC202, CJ1W-OD204, CJ1W-OD212, and CJ1W-OD232.
*2.Available for models with 32 outputs or 64 outputs
Features:?
Name | 8-point Transistor Output Unit with Terminal Block (Sinking Outputs) |
Model | CJ1W-OD201 |
Rated Voltage | 12 to 24 VDC |
Operating Load Voltage Range | 10.2 to 26.4 VDC |
Maximum Load Current | 2.0 A/point, 8.0 A/Unit |
Maximum Inrush Current | 10 A/point, 10 ms max. |
Leakage Current | 0.1 mA max. |
Residual Voltage | 1.5 V max. |
ON Response Time | 0.5 ms max. |
OFF Response Time | 1.0 ms max. |
Insulation Resistance | 20 MΩ between the external terminals and the GR terminal (100 VDC) |
Dielectric Strength | 1,000 VAC between the external terminals and the GR terminal for 1 minute at a leakage current of 10 |
Number of Circuits | 8 (4 points/common, 2 circuits) |
Internal Current Consumption | 90 mA max. |
Fuse | 6.3 A (1/common, 2 used) |
External Power Supply | 12 to 24 VDC, 10 mA min. |
Weight | 110 g max. |
*Terminal numbers A0 to A8 and B0 to B8 are used in the external connection and terminal-device variable diagrams. They are not printed on the Units.
