- Stock: In Stock
- Model: FX1N-2EYT-BD
- Weight: 2.00kg
2. Shipping options include DHL, UPS, FedEx, and EMS.
3. Estimated delivery time for express shipping via DHL, UPS, FedEx, or EMS generally ranges from 3 to 10 business days, depending on the destination country.
4. Please verify your address thoroughly when placing your order.
5. Important for buyers: You are responsible for any tariffs on accessories. To potentially avoid these tariffs, you may choose EMS express shipping.
6. The shipping service is responsible for any accidents, delays, or other issues that may arise.
Returns:
We offer a 14-day return policy. If you wish to return an item, please contact us within 14 days and ensure that the package remains unopened. The buyer is responsible for the shipping costs for both the return and the initial delivery, as well as any applicable customs fees. Once we receive and inspect the product, we will process your refund within 24 hours.
For any quality issues that arise during normal use within the warranty period, we will repair the item free of charge. The buyer is responsible for the return shipping cost, while our company will cover the cost of re-shipping the repaired item.
Introduction
The FX1N-2EYT-BD output expansion board (hereafter referred to as "FX1N-2EYT-BD" or "Function expansion board") is a function expansion board to be installed in the FX1S or FX1N series programmable controller (hereafter referred to as "PLC"), to increase the output of two points.
Features of the FX1N-2EYT-BD
1) Additional increase of two output points.
2) Internal mounting in the top of the PLC meaning no need for change to the installation area of the PLC.
3) Additional outputs have special auxiliary relays associated to each point, which are turned ON or OFF depending on the required output state of the FX1N-2EYT-BD.
As special auxiliary relays are used in the PLC program for the output points, the additional outputs are not included in the regular system I/O count.
Power supply specifications
Item | Specification |
Consumption current | 5V DC Supply by PLC. |
Output specifications
Item | Specification |
External power supply | 5 to 30V DC |
Circuit insulation | Photo coupler |
Operation display | LED lighting when photo coupler is driven |
The maximum resistance load | 0.5A/1 point |
The maximum, inductive load | 12W/24V DC |
Open road leakage current | 0.1mA/DC30V |
Response time OFF to ON | 0.2ms or less |
Response time ON to OFF | 0.2ms or less |
Dimension
