FX-20P-E-SET0 Mitsubishi HANDY PROGRAMMING PANEL Original Brand New

Item

Specifications

Ambient temperature

0 to 40°C

Ambient humidity

35 ~ 85% Relative Humidity, No condensation

Vibration Resistance

- intermittent vibration

Conforms to EN 68-2-6; 10 ~ 57 Hz: 0.075 mm Half Amplitude 57 ~ 150 Hz: 9.8 m/s2Acceleration

Sweep Count for X, Y, Z: 10 times (80 min. in each direction)

Vibration Resistance

- Continuous vibration

Conforms to EN 68-2-6; 10 ~ 57 Hz: 0.035 mm Half Amplitude

57 ~ 150 Hz: 4.9 m/s2Acceleration

Sweep Count for X, Y, Z: 10 times (80 min in each direction)

Shock Resistance

Conforms to EN 68-2-27: 147m/s2Acceleration, Action time 11ms 3 times in each direction X, Y, and Z

Environment

Free from corrosive or flammable gas and excessive conductive dust

Supply voltage

5V DC+-5% supplied from PLC

Current consumption

150 mA*1

User memory capacity

RAM: 16K steps (8K steps in FX-20P-E main units that were manufactured in July 1997 or earlier

with manufacturer serial No.s "77****" or earlier)

Memory backup for power failure

Memory backup capacitor

After being powered for 1 hour it can retain internal device data for 3 days without externally

supplied power

Display unit

Liquid crystal display unit with backlight

Display

contents

Character matrix

1 character: 40 dots (8 × 5), bottom 5 dots of each line (1 × 5 dots) are used for the prompt

Number of characters

64 characters (16 characters × 4 lines)

Character types

Alphanumeric

Keyboard

35 keys

Inbuilt

interface

PLC interface

In conformance to EIA and RS422, connected to FX Series PLC with cable FX-20P-CAB or FX-20P-CAB0.

Extension interface

Connected to extension module

ROM writer function

Available when dedicated module is connected (write, read, collation and deletion check)
