1794-TB3 AB PLC Cage-clamp Terminal Base 1794 Series Original brand new
Terminal Bases
Each FLEX I/O module requires a terminal base unit that snaps onto the DIN rail to the right of the I/O adapter. The terminal bases provide terminal connection points for I/O wiring and plug together to form the backplane. They are available with screw or spring terminations.
Cat. No.♠ | Termination Type | Connections | Used in Applications |
1794-TB2 | Cage-clamp | 16 I/O; 18 common; 2 +V | Up to 132V AC/156V DC |
1794-TB3 | Cage-clamp | 16 I/O; 18 common; 18 +V | Up to 132V AC/156V DC |
1794-TB3S | Spring-clamp | ||
1794-TB3SK | |||
1794-TB32 | Cage-clamp | 32 I/O; 8 common; 8 +V | Up to 31.2V DC |
1794-TB32S | Spring-clamp | ||
1794-TB3G | Cage-clamp | 36 I/O; 2 common; 2 +V; 10 chassis ground | Up to 31.2V DC |
1794-TB3GS | Spring-clamp | ||
1794-TB3GSK | |||
1794-TB3T | Cage-clamp | 16 I/O; 10 common; 4 +V; 8 chassis ground; 2 sets of CJC to be used with temperature modules | Up to 132V AC/156V DC |
1794-TB3TS | Spring-clamp | ||
1794-TB3TSK | |||
1794-TBN | Screw-clamp | 16 I/O; 2 common; 2 +V | 264V AC/DC |
1794-TBNK | |||
1794-TBNF | |||
1794-TBKD | Cage-clamp with 16 knife disconnects | 16 I/O; 18 common; 2 +V | Up to 132V AC/156V DC |
♠ Catalog numbers ending with (K) = Conformal Coated. | |||
