KVM Switcher series USB Auto Switch Rackmount 41UR One year quality assurance NEW

If you need more than 10pcs and want to get better wholesale price, please feel free to contact us by following:
email:[email protected]
Tel:0086-574- 88333153
We will quote you our best price to you in 24hours.

41UR KVM Switcher

Product Features:

1, more computer switches exquisite appearance, easy to install.

2, support the micosoft lntellimouse, logitech wet mouse and other mouse

3, support win98/ME/2KP4/XP/2003, linux, Apple, MAC and other operating systems.

4, support hot-swappable, can be free to change the computer, without the need to shut down,

5, support display resolution of 1920 * 1440 @ 60HZ, Bandwidth 200MHZ

6, plug-and-play, no software

7, switching mode: front button switch, (2) the keyboard to switch

8, ON LINK indicator shows the current status of the

9, with audio feedback when switching

10, with audio switch

11 with USB2.0HUB mouth

Installation instructions:

1, please use the dedicated band audio, USB KVM cable

2, one end of the KVM cable to the computer's USB, the display interface KVM switch on the other end to the USB, audio, and display (PC interface) interface, repeat the above steps, all computer cables and KVM connection.

3, the control terminal USB, audio, display, respectively, (ie, control port connected to the console port on the KVM)

4, check the connections to ensure that the cable is properly connected

5, the external power supply is connected, the POWER indicator lights (KVM CABLE line less than 30M or current voltage is sufficient, the keyboard and mouse powered no external power supply)

6 Turn on the computer to boot,

Instructions for use:

1, key switch: random switching can be the key.

2, the host can online testing, each host can each interval of five seconds at the same time to boot, Note:

When the computer is turned on, do not switch, in order to avoid mistakes, can switch back and fully open when the host after switching the mouse and keyboard can not operated simultaneously (mobile) in order to avoid a dead keyboard and mouse

3 hotkeys: eKL-21UR press the Ctrl or scrlk key secondary, eKL-41U/P21U ({scrlk} key twice + direction key [↑ ↓ → ←

Note: (1) use only or open a host PC can not switch, only the simultaneous use of two or more host PC before they can switch with each other.

    ? When the shutdown, if there is a closed, it will automatically jump to another host interface.

? hot-key keypad, digital role.

Power; 5v

Specifications:
