KVM Switcher series USB 4 ports ekl-41U One year quality assurance NEW

If you need more than 10pcs and want to get better wholesale price, please feel free to contact us by following:
email:[email protected]
Tel:0086-574- 88333153
We will quote you our best price to you in 24hours.

ekl-81UK (new) KVM Switcher

Description:

Note; USB mouse must be linked to the product above the first USB port.

    More than one computer switch exquisite appearance, easy to install.

    2 support micosoft lntellimouse, logitech Net mouse, and other mouse

    3 win98/ME/2KP4/XP/2003, linux, Apple, MAC operating system.

    4 hot-swappable, can be free to change the computer, without the need to shut down,

    5 supports display resolution of 1920 * 1440 @ 60HZ, Bandwidth 200MHZ

    6 Plug and Play, no software

    7 switching method: (1) front button switch, (2) the keyboard to switch

    8 ON LINK indicator displays the current status

    9 Switch with audio feedback

    10 with audio switch

    11 with a USB port

Installation instructions:

Note; USB mouse must be linked to the product above the first USB port.

1, please use the dedicated band audio, USB KVM cable

2, one end of the KVM cable connected to the computer's USB, audio, display interface on the other end to the KVM Switch USB, audio, and display (PC interface) interface, repeat the above steps, all computers cables and KVM linking.

3, the control terminal USB, audio, display, respectively, (ie, control port connected to the console port on the KVM)

4, check the connections to ensure that the cable is properly connected

5 Turn on the computer to boot,

Instructions for use:

1, key switch: random switching can be the key.

2, the host can online testing, each host can each interval of five seconds at the same time to boot, Note:

When the computer is turned on, do not switch, in order to avoid mistakes, can switch back and fully open when the host after switching the mouse and keyboard can not operated simultaneously (mobile) in order to avoid a dead keyboard and mouse

3 hotkeys: eKL-21U / / P21U press the Ctrl key twice, ekl-41U/41UR (scroll lock) key twice + the arrow keys.

Note: (1) use only or open a host, PC can not switch only hosts more than at the same time, PC can switch between.  hot-key keypad, digital role.

Specifications:
