AV to HDMI Converter

Description:

1 CVBS or S-Video signal up to HDTV 1080p.

2. HDMI output 1080P (50-60HZ)

3. AUDIO into HDMI where and by 3.5mm headphone jack output.

4 video input system: NTSC / PAL (automatic detection CVBS format).

5. CVBS and S-Video signals can be input converter, switch the input signal through the band switch.

Interface Description:

1.S-Video IN: S-CVBS line access to the equipment (DVD / VCD) S terminal.

2.VIDEO IN: AV cable access to the equipment (DVD / VCD) CVBS composite video terminals.

AUDIO / R IN: AUDIO line access to the R terminal equipment (DVD / VCD) sound.

AUDIO / L IN: AUDIO line access to the L terminal equipment (DVD / VCD) sound.

3. DC 5V: access DC 5V power supply.

4.POWER: when access to power, the LED lights.

5.SWITCH: input signal CVBS and S-Video to be switched.

6.AUDIO OUT: Output Stereo L / R (3.5mm headphone jack).

7. HDMI OUT: output to the HDMI INPUT of the HDMI display device.

Function Description:

1. Input system:

Video systems: (1) CVBS (NTSC / PAL) (automatic detection formats);

          ? S-Video;

Audio Systems: analog stereo audio (L / R).

2. Input port:

CVBS: Composite video input 1vpp 75ohm;

S-Video: Y / C video signal input 1vpp 75ohm;

   AUDIO (R / L): 3vpp 47ohm.

3 Output System:

Video System: 720p 60Hz

Audio system: a 3.5mm headphone jack output.

4. Output port:

One HDMI output;

The AUDIO output all the way.

5. Use the power supply: DC 5V/2A,

Dimensions: 110 (L) x 70 (W) x25 (H) mm

Weight: 0.35kg
