SIEMENS Touch Screen Smart Line700 6AV6 648-0AC11-3AX0 upgraded to 648-0BC11-3AX0

SIEMENS Touch Screen Smart Line700 6AV6 648-0AC11-3AX0 upgraded to 648-0BC11-3AX0

Display: 7" color LCD-TFT

Resolution: 800 × 480

Color: 256 colors

Brightness: 250 cd / m

Backlight life: > 40,000 hours

Touch Screen: 4-wire precision resistor network (surface hardness 4H)

CPU: the ARM 400HZ

Memory: 8MB Flash + 64DDR SDRAM

Real-Time Clock: software clock

Communication ports: 1RS422/RS485

Communication rate of 187.5kbits / s

Power supply: 24 VDC

Allowable voltage :19.2-28 .8 VDC

Before the board size: 213 * 159

mmInstallation hole size: 192 × 138 mm

Operating temperature ?0 to -50 degrees (vertical installation)

Transport temperature: -20 degrees and -60 degrees

Maximum humidity: 95% non-condensing

Degree of protection: front panel IP65Back: IP20

Software: Wincc flexble China SP2 + HSPCan be connected to the PLC: S7-200Third-party PLC: Mitsubishi FX 500 OMRON CP1 variable number of screens 50Recipe: 5Alarm System: 200/32 (the number of alarms / alarm level) High-resolution widescreen display1,800 × 480 dpi widescreen display design and compared to traditional screen has a larger viewing area, so that a single screen can display more information, allowing the operator to have a more comfortable viewing experienceLED backlight, saving energy

1, the LED compared to CCFL backlight thickness reduced by about half, the wonderful series of panel is more lightweight. At the same time, the higher the operating screen brightness, the color is more uniform, more expressive, visual range increased to 140 °

2, the LED backlight can reduce equipment energy consumption, combined with the screen saver function to extend the life of the operation screenPowerful and rich communications capabilities1, the PPI communication protocol to ensure that the wonderful series of panel and S7-200 to establish high-speed seamless connectivity, and S7-200 PLC perfect small automation solutions2, the integrated RS 422/485 communications port wonderful series of panel communications more flexible, and the small PLC market mainstream to the establishment of a stable and reliable communications connection.

(Mitsubishi FX series; OMRON CP1 range)3, when the use of PPI's communications, the communication rate of up to 187.5kb / s,High-performance processors, high-speed external bus and 64M DDR memoryA high-end ARM processor speeds up to 400MHz, the data processing faster, smoother screen display2, high-speed external bus full play to the strong performance of the processor3, enhanced 64M DDR memory makes the screen to switch faster
