Products Description
Mitsubishi 5.7" HMI F940GOT-SWD-C
The graphical F900GOT units combine simple operation with powerful performance and minimum space requirements. Machine operation sequences are clearly comprehensible on the configurable display, ensuring that operators can easily understand the situation and respond quickly.
In addition to the powerful standard diagnostics and display functions these control units also support user-programmable graphical images. Operators can store up to 500 user-defined images, three of which can be displayed interchangeably on the LC screen using an overlay function.
Product range
Specifications | F940WGOT | F940GOT-SWD-E | F940GOT-LWD-E | F940/943GOT | F930GOTBWD-E |
Display unit | TFT, 256 colours backlight | TFT, 256 colours backlight | LCD, monochrom, backlight | STN, 8 colours, sw backlight | STN, 2 colours |
Display format (WxH) | 155,5 x 87,5 mm | 115 x 86 mm | 115 x 86 mm | 115 x 86mm | 117 x 42 mm |
Resolution; characters x lines (pixles) | 60 x 14 (29 x 30) | 40 x 15 (320 x 240) | 15 x 5 (320 x 240) | 40 x 15 (320 x 240) | 160 x 50 (240 x 80) |
Applicable PLC | All MELSEC PLC Systems | All MELSEC PLC Systems | All MELSEC PLC Systems | All MELSEC PLC Systems | All MELSEC PLC Systems |
Printer interface | RS232C | RS232C | RS232C | RS232/RS422 | RS232C |
Memory type | Flash-RAM | RAM | RAM | Flash-RAM | Flash-RAM |
External I/O connectors | 3 | 2 | 2 | 2 | 2 |
Real-time clock | Integrated | Integrated | Integrated | Integrated | Integrated |
Keyboard | Touchpanel | Touchpanel | Touchpanel | Touchpanel | Touchpanel |
Function keys | Up to 50 Touchkeys/screen | Up to 240 Touchkeys | Up to 240 Touchkeys | Up to 50 Touchkeys/screen | Up to 50 Touchkeys |
LED indicators | 1 (POWER) | — | 1 (POWER) | 6 | 1 (POWER) |
Weight | 0.79 kg | 1.0 kg | 1.0 kg | 0.79 kg | 0.3 kg |
Dimensions (WxHxD) mm | 215 x 133 x 70,6 | 170 x 130 x 52 | 170 x 130 x 52 | 156 x 191x 63,5 | 146 x 75 x 49 |
