Product Description:
High-speed 300 μs, the Response
The amplifier includes a 300 us high-speed response mode. As an example of the speed provided, the system is capable of detecting marks that are 1 mm wide on a web being fed at a speed of 3.3 m / s. (HSPD = during high-speed the mode operation)
Built in Self-stabilizer
The self-stabilizer monitors variations in the amount of light produced by each LED and works to ensure the light is transmitted is maintained at a constant and uniform level. Thiscancels the effects of temperature fluctuations and the passage of time on the efficiency of transmitter light.
Eight-color the Registration and External Tuning
The 8-bank switching feature allows you to store 8 settings in the amplifier's memory and switch among them using an external signal generated by a PLC. There is also an external tuning feature that lets you use an external device such as a push-button to the trigger the SET operation.
Type | Main unit | |
Model | NPN | CZ-K1 |
PNP | CZ-K1P | |
Light source | Red LED, Green LED, Blue LED | |
Response time | 300 µs/1 ms (switch-selectable) | |
Operation mode | Match output: Turns on when target colour matches registered colour. Mismatch output: Turns on when target colour is different from registered colour. (switch-selectable) | |
Timer function | OFF-delay timer (40 ms)/Timer OFF (switch-selectable) | |
Control output | NPN or PNP 40 VDC max. (100 mA max.), Residual voltage: 1.0 V max. | |
Power supply | 12 to 24 VDC ±10%, Ripple (P-P): 10% max. | |
Ambient light | Incandescent lamp: 5,000 lux max., Sunlight: 10,000 lux max. | |
Ambient temperature | -10°C to +55°C (14 to 131°F), No condensation | |
Relative humidity | 35 to 85%, No condensation | |
