CS1784 ATEN USB 2.0 DVI KVM Switch 4-port Desktop

If you need more than 10pcs and want to get better wholesale price, please feel free to contact us by following:
email:[email protected]
Tel:0086-574- 88333153
We will quote you our best price to you in 24hours.

Product Features

 A set of USB console controls 4 computers and two additional USB peripherals

 Built-in 2-port USB 2.0 Hub

 Compatible with USB 2.0 specifications

 Full mega bass response capability, can support 2.1-channel surround audio output system, and provide high-quality sound

 Console audio port located on the front panel to access easily, suitable for connecting of Internet phone

 Support computer USB peripherals, and audio functions switch independently

 Support DVI-Digital and DVI-Analog display - fully compatible with DVI specifications and HDCP specifications

 High video resolution - Support up to 2560 x 1600 (DVI Single Link) *; 2048 x 1536; DDC2B (DVI-A)

 Support wide screen video resolution

 Via front panel pushbuttons and hotkeys to switch the computer

 Console mouse port emulation / bypass function support full mouse drivers and multifunction mice

 DynaSync display- store console display's EDID (Extended Display Identification code) to optimize display resolution

 Compatible with HDCP

 Keyboard signal simulation, ensure error-free booting

 Support and emulate Sun / Mac keyboard **

 Automatic Scanning function to monitor computer operation

 Support firmware update

 Support cross-platform -Windows 2000/XP/Vista, Linux, Mac and Sun

* 2560 x 1600 @ 60Hz (DVI Dual Link); 3840 x 2400 13Hz (DVI Single Link) only support specific video resolution

** 1. PC keyboard combinations can emulate Sun / Mac keyboard

2. Sun / Mac keyboards can be used only with Sun / Mac computers

 Package Contents

 1x USB 2.0 DVI multi-computer switch

 4x specially crafted DVI Dual Link Cable Sets (DVI-D)

 1x USB to PS / 2 converter

 The 1x firmware update wire

 1x Power Adapter

 1x User Manual

 1x Quick Start Guide

Specifications
