- Stock: In Stock
- Model: VFDB2022
- Weight: 16.00kg
2. Shipping options include DHL, UPS, FedEx, and EMS.
3. Estimated delivery time for express shipping via DHL, UPS, FedEx, or EMS generally ranges from 3 to 10 business days, depending on the destination country.
4. Please verify your address thoroughly when placing your order.
5. Important for buyers: You are responsible for any tariffs on accessories. To potentially avoid these tariffs, you may choose EMS express shipping.
6. The shipping service is responsible for any accidents, delays, or other issues that may arise.
Returns:
We offer a 14-day return policy. If you wish to return an item, please contact us within 14 days and ensure that the package remains unopened. The buyer is responsible for the shipping costs for both the return and the initial delivery, as well as any applicable customs fees. Once we receive and inspect the product, we will process your refund within 24 hours.
For any quality issues that arise during normal use within the warranty period, we will repair the item free of charge. The buyer is responsible for the return shipping cost, while our company will cover the cost of re-shipping the repaired item.
Introduction
VFDB braking units are applied to absorb the motor regeneration energy when the three-phase induction motor stops by deceleration. With VFDB braking unit, the regeneration energy will be dissipated in dedicated braking resistors. To prevent mechanical or human injury, please refer to this instruction sheet before wiring. VFDB braking units are suitable for DELTA AC Motor Drives VFD Series 230V/460V/575V. VFDB braking units need to be used in conjunction with BR series braking resistors to provide the optimum braking characteristics
Specifications
VFDB Braking Units
Specification | 230V Series | 460V Series | 575V Series | |||
Model VFDB | 2015 | 2022 | 4030 | 4045 | 5055 | |
Max. Motor Capacity (KW) | 15 | 22 | 30 | 45 | 55 | |
Output Rating | Max. Discharge Current (A) 10%ED | 40 | 60 | 40 | 60 | 60 |
Continuous Discharge Current (A) | 15 | 20 | 15 | 18 | 20 | |
Braking Start-up Voltage (DC) | 330/345/360/380/440/415+-3V | 660/690/720/760/800/830+-6V | 950+-8V | |||
Input Rating | DC Voltage | 200—400VDC | 400—800VDC | 607-1000VDC | ||
Min. Equivalent Resistor for Each Braking Unit | 10 ohm | 6.8 ohm | 20 ohm | 13.6 ohm | 15.8 ohm | |
Protection | Heat Sink Overheat | Temperature over +950C (203oF) | ||||
Alarm Output | Relay contact 5A120VAC/28VDC (RA, RB, RC) | |||||
Power Charge Display | Blackout until bus (+~-) voltage is below 50VDC | |||||
Environment | Installation Location | Indoor (no corrosive gases, metallic dust) | ||||
Operating Temperature | -100C~+500C (14oF to 122oF) | |||||
Storage Temperature | -200C~+600C (-4oF to 140oF) | |||||
Humidity | 90% Non-condensing | |||||
Vibration | 9.8m/s2 (1G) under 20Hz 2m/s2 (0.2G) at 20~50Hz | |||||
Mechanical Configuration | Wall-mounted enclosed type IP50 | |||||
