- Stock: In Stock
- Model: D5B-8013
- Weight: 0.02kg
2. Shipping options include DHL, UPS, FedEx, and EMS.
3. Estimated delivery time for express shipping via DHL, UPS, FedEx, or EMS generally ranges from 3 to 10 business days, depending on the destination country.
4. Please verify your address thoroughly when placing your order.
5. Important for buyers: You are responsible for any tariffs on accessories. To potentially avoid these tariffs, you may choose EMS express shipping.
6. The shipping service is responsible for any accidents, delays, or other issues that may arise.
Returns:
We offer a 14-day return policy. If you wish to return an item, please contact us within 14 days and ensure that the package remains unopened. The buyer is responsible for the shipping costs for both the return and the initial delivery, as well as any applicable customs fees. Once we receive and inspect the product, we will process your refund within 24 hours.
For any quality issues that arise during normal use within the warranty period, we will repair the item free of charge. The buyer is responsible for the return shipping cost, while our company will cover the cost of re-shipping the repaired item.
Product Description:
Detects Objects in Multiple Directions with High Sensitivity, Ideal for Robotics
• Slow-action switching mechanism used.
• Gold-plated contact with coil spring capable of switching micro current/voltage load while providing high contact reliability.
• Inputs directly to microcomputers and programmable controllers.
• Three sizes (M10, M8, and M5) and three types of compact actuators.
• Easy panel mounting.
Specifications:
Degree of protection | IP67 | |
Durability *1 | Mechanical | 10,000,000 operations min. |
Electrical | 5,000,000 operations min. (at 30 mA 30 VDC resistive load) | |
Operating speed | 5 to 500 mm/s | |
Operating frequency | Mechanical | 120 operations/min. |
Electrical | 60 operations/min. | |
Insulation resistance | 100 M? min. at 250 VDC between each terminal and non-current-carrying metal parts | |
Contact resistance | With 1 m cable:700 m? max. (initial value) With 3 m cable:1.9 ? max. (initial value) With 5 m cable:3.1 ? max. (initial value) | |
Dielectric strength (50/60 Hz 1min) | Between terminals of same polarity | 250 VAC (at TTP) |
Between each terminal and non-current-carrying metal parts | 1,000 VAC (600 VAC for M5 model) | |
Vibration resistance | Malfunction | 10 to 55 Hz, 1.5-mm double amplitude *2 |
Shock resistance | Mechanical | 1,000 m/s2 min. |
Malfunction | 300 m/s2 min. *3 | |
Ambient operating temperature | −10°C to +70°C (with no icing) | |
Ambient operating humidity | 35% to 95%RH | |
Actuator strength | 14.7 N *4 | |
Weight | Switch | M5: Approx. 14 g, M8: Approx. 20 g, M10: Approx. 21 g |
Cable | Approx. 10 g/m | |
