6ES7132-4BB00-0AA0 SIEMENS ELECTRONIC MODULE FOR ET 200S New

Supply voltage

Reverse voltage protection

Yes; when using the same load voltage as on the power module

Load voltage L+

Rated value (DC)

24 V; From power module

Reverse polarity protection

Yes

Input current

from load voltage L+ (without load), max.

5 mA; per module

from backplane bus 3.3 V DC, max.

10 mA

Power losses

Power loss, typ.

0.4 W

Address area

Address space per module

with packing

2 bit

without packing

1 byte

Digital outputs

Number/binary outputs

2

Functionality/short-circuit strength

Yes; Per channel

Response threshold, typ.

0.7 to 1.8 A

Limitation of inductive shutdown voltage to

-55 to -60 V

Lamp load, max.

5 W

Controlling a digital input

Yes

Load resistance range

lower limit

48 Ω

upper limit

3400 Ω

Output voltage

for signal "1", min.

L+ (-1 V)

Output current

for signal "1" rated value

0.5 A

for signal "1" permissible range for 0 to 60 °C, min.

7 mA

for signal "1" permissible range for 0 to 60 °C, max.

600 mA

for signal "0" residual current, max.

0.3 mA

Output delay with resistive load

0 to "1", max.

200 µs

1 to "0", max.

1.3 ms

Parallel switching of 2 outputs

for increased power

No

for redundant control of a load

Yes; per module

Switching frequency

with resistive load, max.

100 Hz

with inductive load, max.

2 Hz

on lamp load, max.

10 Hz

Aggregate current of outputs (per group)

all mounting positions

up to 60 °C, max.

1 A

Cable length

Cable length, shielded, max.

1000 m

Cable length unshielded, max.

600 m

Isochronous mode

Isochronous operation (application synchronized up to terminal)

No

Interrupts/diagnostics/status information

Diagnostic messages

Diagnostic functions

No

Diagnostics indication LED

Status indicator digital output (green)

Yes

Parameter

Remark

1 byte

Galvanic isolation

Galvanic isolation digital outputs

between the channels

No

between the channels and the backplane bus

Yes

Permissible potential difference

between different circuits

75 VDC / 60 VAC

Isolation

Isolation checked with

500 V DC

Dimensions

Width

15 mm

Height

81 mm

Depth

52 mm

Weight

Weight, approx.

40 g
