AFPX-C60TD FP-X C60TD Panasonic PLC CPU 24VDC 32 Point Input 28DO Transistor NPN 32K Steps USB Port New Original 1Year W

AFPX-C60TD FP-X C60TD Panasonic PLC CPU 24VDC 32 Point Input 28DO Transistor NPN 32K Steps USB Port New Original 1Year W
AFPX-C60TD FP-X C60TD Panasonic PLC CPU 24VDC 32 Point Input 28DO Transistor NPN 32K Steps USB Port New Original 1Year W
AFPX-C60TD FP-X C60TD Panasonic PLC CPU 24VDC 32 Point Input 28DO Transistor NPN 32K Steps USB Port New Original 1Year W
AFPX-C60TD FP-X C60TD Panasonic PLC CPU 24VDC 32 Point Input 28DO Transistor NPN 32K Steps USB Port New Original 1Year W
AFPX-C60TD FP-X C60TD Panasonic PLC CPU 24VDC 32 Point Input 28DO Transistor NPN 32K Steps USB Port New Original 1Year W
FP-X C60TD AFPX-C60TD Panasonic PLC 24VDC 32 DC input points 28 NPNoutput points FP-X Control Unit O... Read More
0 reviews • Write a review
$354.00
Ex Tax: $354.00
  • Stock: In Stock
  • Model: AFPX-C60TD
  • Weight: 1.00kg
Add to Cart
Buy Now Question?
Add to Wish List Compare this Product

1. We typically ship items within three business days after payment is received.
2. Shipping options include DHL, UPS, FedEx, and EMS.
3. Estimated delivery time for express shipping via DHL, UPS, FedEx, or EMS generally ranges from 3 to 10 business days, depending on the destination country.
4. Please verify your address thoroughly when placing your order.
5. Important for buyers: You are responsible for any tariffs on accessories. To potentially avoid these tariffs, you may choose EMS express shipping.
6. The shipping service is responsible for any accidents, delays, or other issues that may arise.

Returns:
We offer a 14-day return policy. If you wish to return an item, please contact us within 14 days and ensure that the package remains unopened. The buyer is responsible for the shipping costs for both the return and the initial delivery, as well as any applicable customs fees. Once we receive and inspect the product, we will process your refund within 24 hours.
For any quality issues that arise during normal use within the warranty period, we will repair the item free of charge. The buyer is responsible for the return shipping cost, while our company will cover the cost of re-shipping the repaired item.

We accept many payments,include Paypal,Bank Transfer etc
8DI 6DO Transistor 100?40VAC Mitsubishi FX3G-14MT-ES-A PLC for upgrade FX1N
Quickview
8DI 6DO Transistor 100?40VAC Mitsubishi FX3G-14MT-ES-A PLC for upgrade FX1N
$178.00
Ex Tax:$178.00
Add to Cart Add to Wish List Compare this Product
8DI 6DO Transistor 24V DC Mitsubishi FX3G-14MT-DSS PLC for upgrade FX1N
Quickview
8DI 6DO Transistor 24V DC Mitsubishi FX3G-14MT-DSS PLC for upgrade FX1N
$214.00
Ex Tax:$214.00
Add to Cart Add to Wish List Compare this Product
AFC8503S Panasonic 3m Cable FP computer connection Original New
Quickview
AFC8503S Panasonic 3m Cable FP computer connection Original New
$38.00
Ex Tax:$38.00
Add to Cart Add to Wish List Compare this Product
AFP02123 PLC AFP0 serial NEW FP0-C10RS
Quickview
AFP02123 PLC AFP0 serial NEW FP0-C10RS
$125.00
Ex Tax:$125.00
Add to Cart Add to Wish List Compare this Product
AFP02123C Programmable Controllers FP0-C10CRS
Quickview
AFP02123C Programmable Controllers FP0-C10CRS
$170.00
Ex Tax:$170.00
Add to Cart Add to Wish List Compare this Product
AFP02223 Programmable Controllers PLC FP0-C14RS
Quickview
AFP02223 Programmable Controllers PLC FP0-C14RS
$149.00
Ex Tax:$149.00
Add to Cart Add to Wish List Compare this Product
AFP02223C Programmable Controllers PLC FP0-C14CRS
Quickview
AFP02223C Programmable Controllers PLC FP0-C14CRS
$187.00
Ex Tax:$187.00
Add to Cart Add to Wish List Compare this Product
AFP02343 Programmable ControllersPLC FP0-C16T
Quickview
AFP02343 Programmable ControllersPLC FP0-C16T
$154.00
Ex Tax:$154.00
Add to Cart Add to Wish List Compare this Product
Tags: AFPX-C60TD

FP-X C60TD AFPX-C60TD Panasonic PLC 24VDC 32 DC input points 28 NPNoutput points FP-X Control Unit Original New


Features

•     High-speed Operation

The 32-bit RISC processor provides the top-level processing speed in compact PLCs. The scan time is 2 ms or less for 5,000 steps. A high-speed PLC is indispensable for enhancing the functionality of equipment.

•     Large Capacity Program Memory

FP-X, which is equipped with 32k steps*2 program memory, is ideal for fully covering the increasing functions, such as communications, positioning, and analog control. The sufficient program capacity can also support future equipment modifications.

•     Independent Comment Memory

There are difficulties with program management on a PC, such as identifying the latest program. The use of the program in the PLC of equipment in operation is often regarded as the best option. Since FP-X has an independent comment memory, all comments can be stored in the PLC together with programs, facilitating program management and maintenance.

•     Maximum Number of I/O Points

Since up to eight expansion units can be connected to one control unit, the maximum number of I/O points is 300. Furthermore, with the add-on cassette and expansion FP0 adapter connected, the number of I/O points can be increased to 382.

•     Built-in 4-axis Pulse Output (Transistor Output Type)

The transistor output type C14 comes with 3-axis while C30/60 comes with 4-axis pulse output built-in the control unit. The multi-axis control, which previously required a higher-level PLC or additional positioning unit, or two or more PLC units, can now be achieved with only one FP-X transistor output type unit in a small space at a low cost. In addition, as this type does not require a pulse I/O cassette needed for a relay output type, other function expansion cassettes such as communication or analog input can be attached for more diversified applications.

•     Modbus-RTU

Communicates with equipment compatible with Modbus-RTU

•     Expansion Cassettes

Expansion cassettes are available for Extra digital I/O, analog, motion, Ethernet, Serial communication, etc.

General Specifications

Item

Description

Relay output type

Transistor output type

Power supply and I/O Specifications

Power supply

100 to 240 V AC (AC power), 24 V DC (DC power)

Input

24V DC °C common

Output

2 A

0.5 A

Service power supply
(AC power type only)

0.15 A (C14)/ 0.4 A (C30/ C60)

Performance Specifications

Number of I/O points

C14

Input: 8 points, Output: 6 points

C30

Input: 16 points, Output: 14 points

C60

Input: 32 points, Output: 28 points

I/O points when expanded

C14

Max. 328 points (When using FP0 expansion units and add-on cassette)

C30

Max. 352 points (When using FP0 expansion units and add-on cassette)

C60

Max. 382 points (When using FP0 expansion units and add-on cassette)

Operation speed

0.32μs/step

Program memory

Flash ROM built-in (no battery backup required)

Program capcity

16 ksteps (C14), 32 ksteps (C30, C60)

Basic instructions

111

Applied instructions

216

Operation memory

Internal relay ®

4096 points

Timer/counter (T/C)

1024 points

Data register (DT)

12285 words (C14), 32765 (C30, C60)

Special functions

Pulse catch input

14 points

14 points

Interrupt input

14 points

14 points

Analog I/O

Input: Max. 24 ch, Output: Max. 12 ch (When using FP0 analog unit)
Input: Max. 4 ch (When using add-on cassette)

Volume input

2 points (C14/C30), 4 points (C60)

High-speed counter

Input of main unit

Single-phase: 8 ch x Max. 10 kHz
2-phase: 4 ch Max. 5 kHz

Single-phase: 8 ch (High-speed: 4 ch, midium-speed: 4 ch)
2-phase: 4 ch (High-speed: 2 ch, midium-speed: 2ch)

With high-speed single-phase:
1 ch x Max. 100 kHz
2 ch x Max. 80 kHz
3 ch x Max. 60 kHz
4 ch x Max. 50 kHz
With high-speed 2-phase:
1 ch x Max. 35 kHz
2 ch x Max. 25 kHz
With medium-speed single-phase:
4 ch x Max. 10 kHz each
With Medium-speed 2-phase:
2 ch x Max. 5 kHz each

when pulse I/Ocassette installed

Single-phase: 2 ch x Max. 80 kHz, 4 ch x Max. 50 kHz
2-phase: 1 ch x Max. 30 kHz, 2 ch x Max. 25 kHz

Pulse I/O cassette cannot be installed.

Pulse output

Input of main unit

-

With high-speed 2 ch x Max. 100 kHz
For linear interpolation, compositespeed: 100 kHz
With medium-speed 2 ch x Max. 20 kHz
For linear interpolation, compositespeed: 20 kHz

when pulse I/Ocassette installed

1 ch x Max. 100 kHz, 2ch x Max. 80 kHz

Pulse I/O cassette cannot be installed.

Serial interface

RS232C.RS485, USB, Ethernet

Network function

PLC Link, Computer link, Modem, Modbus-RTU

Other functions

Program editing during RUN, Constant scan, 8-digit password, Program

Control Units

Model Name

Power

Pulse Outputs

Modbus Rtu

Dc Inputs

Npn Outputs

Pnp Outputs

Relay Outputs

Program Size (K)

AFPX-C14P

AC100-240V

3 Axis

Yes

8



6



12

AFPX-C14PD

24VDC

3 Axis

Yes

8



6



12

AFPX-C14R

AC100-240V

No

Yes

8





6

12

AFPX-C14T

AC100-240V

3 Axis

Yes

8

6





12

AFPX-C14TD

24VDC

3 Axis

Yes

8

6





12

AFPX-C30P

AC100-240V

4 Axis

Yes

16



14



32

AFPX-C30PD

24VDC

4 Axis

Yes

16



14



32

AFPX-C30R

AC100-240V

No

Yes

16





14

32

AFPX-C30T

AC100-240V

4 Axis

Yes

16

16





32

AFPX-C30TD

24VDC

4 Axis

Yes

16

16





32

AFPX-C60P

AC100-240V

4 Axis

Yes

32



28



32

AFPX-C60PD

24VDC

4 Axis

Yes

32



28



32

AFPX-C60R

AC100-240V

No

Yes

32





28

32

AFPX-C60T

AC100-240V

4 Axis

Yes

32

28





32

AFPX-C60TD

24VDC

4 Axis

Yes

32

28





32
