SV037iG5-4 LS Electrogenesis converter iG5 series NEW

SV***iG5A-1***

004

008

015

Max.
capacity 1)

(HP)

0.5

1.9

2

(kW)

0.4

0.75

1.5

Output
rating

Capacity (kVA) 2)

0.95

1.9

3.0

FLA (A) 3)

2.5

5

8

Max frequency

400 [Hz] 4)

Max voltage

3 phase 200~230V 5)

Input
rating

Rated voltage

1 phase 200~230 VAC (+10%, -15%)

Rated frequency

50~60 [Hz] (±5%)

Cooling method

Forced air cooling

Weight (kg)

0.76

1.12

1.84

Control

Control method

V/F, Sensorless vector control

Frequency setting resolution

Digital command: 0.01Hz
Analog command: 0.06Hz (Max. freq.: 60Hz)

Frequency accuracy

Digital command: 0.01% of Max. output frequency
Analog command: 0.1% of Max. output frequency

V/F pattern

Linear, Squared, User V/F

Overload capacity

150% per 1 min.

Torque boost

Manual/Auto torque boost

Dynamic
braking

Max. braking
torque

20% 1)

Max. Duty

150% when using optional DB resistor 2)

Operation

Operation mode

Keypad/ Terminal/ Communication option/ Remote keypad selectable

Frequency setting resolution

Analog: 0~10V, -10~10V, 0~20mA
Digital: Keypad

Operation features

PID, Up-down, 3-wire

Input

Multi-function
terminal
P1-P8

NPN/PNP selectable

FWD/REV RUN, Emergency stop, Fault reset, Jog operation, Multi-step Frequency-High, Mid, Low,
Multi-step Accel/Decel-High, Mid, Low, DC braking at stop, 2nd motor select, Frequency UP/Down,
3-wire operation, External trip A, B, PID-Inverter (V/F) operation bypass,
Option-inverter (V/F) operation bypass, Analog Hold, Accel/Decel stop

Output

Open collector
terminal

Fault output and
inverter status output

Less than DC 24V, 50mA

Multi-function relay

(N.O., N.C.) Less than AC 250V, 1A; Less than DC 30V, 1A

Analog output (AM)

0~10Vdc (less than 10mA): Output freq, Output current, Output voltage, DC link selectable

Protective
function

Trip

Over voltage, Under voltage, Over current, Ground fault current detection, Inverter overheat,
Motor overheat, Output phase open, Overload protection, Communication error,
Loss of speed command, Hardware fault, Fan trip

Alarm

Stall prevention, Overload

Momentary power loss

Below 15 msec.: Continuous operation (Should be within rated input voltage, rated output power.)
Above 15 msec.: Auto restart enable

Environ
ment

Protection degree

IP 20, NEMA1 (Optional)

Ambient temp

-10?~50?

Storage temp

-20?~65?

Humidity

Below 90% RH (No condensation)

Altitude/Vibration

Below 1,000m, 5.9m/sec2 (0.6G)

Atmospheric pressure

70~106 kPa

Location

Protected from corrosive gas, Combustible gas, Oil mist or dust
