CB-114 MOXA PC/104 Multiple serial boards 4-port RS-232/422/485 PC/104 + modules

CB-114 MOXA PC/104 Multiple serial boards 4-port RS-232/422/485 PC/104 + modules
CB-114 MOXA PC/104 Multiple serial boards 4-port RS-232/422/485 PC/104 + modules
CB-114 MOXA PC/104 Multiple serial boards 4-port RS-232/422/485 PC/104 + modules
CB-114 MOXA PC/104 Multiple serial boards 4-port RS-232/422/485 PC/104 + modules
CB-114 MOXA PC/104 Multiple serial boards 4-port RS-232/422/485 PC/104 + modules
CB-114 MOXA PC/104 Multiple serial boards 4-port RS-232/422/485 PC/104 + modulesIf you need more tha... Read More
0 reviews • Write a review
$416.00
Ex Tax: $416.00
  • Stock: In Stock
  • Model: PC/104
  • Weight: 0.30kg
Add to Cart
Buy Now Question?
Add to Wish List Compare this Product

1. We typically ship items within three business days after payment is received.
2. Shipping options include DHL, UPS, FedEx, and EMS.
3. Estimated delivery time for express shipping via DHL, UPS, FedEx, or EMS generally ranges from 3 to 10 business days, depending on the destination country.
4. Please verify your address thoroughly when placing your order.
5. Important for buyers: You are responsible for any tariffs on accessories. To potentially avoid these tariffs, you may choose EMS express shipping.
6. The shipping service is responsible for any accidents, delays, or other issues that may arise.

Returns:
We offer a 14-day return policy. If you wish to return an item, please contact us within 14 days and ensure that the package remains unopened. The buyer is responsible for the shipping costs for both the return and the initial delivery, as well as any applicable customs fees. Once we receive and inspect the product, we will process your refund within 24 hours.
For any quality issues that arise during normal use within the warranty period, we will repair the item free of charge. The buyer is responsible for the return shipping cost, while our company will cover the cost of re-shipping the repaired item.

We accept many payments,include Paypal,Bank Transfer etc
10/100M TCP/IP to Fiber transceiver-1 TCP/IP Port UT-2671SM NEW
Quickview
10/100M TCP/IP to Fiber transceiver-1 TCP/IP Port UT-2671SM NEW
$86.00
Ex Tax:$86.00
Add to Cart Add to Wish List Compare this Product
10/100M TCP/IP to Fiber transceiver-2 TCP/IP Port UT-2672SM NEW
Quickview
10/100M TCP/IP to Fiber transceiver-2 TCP/IP Port UT-2672SM NEW
$80.00
Ex Tax:$80.00
Add to Cart Add to Wish List Compare this Product
10/100M TCP/IP to Fiber transceiver-4 TCP/IP Port UT-2674SM NEW
Quickview
10/100M TCP/IP to Fiber transceiver-4 TCP/IP Port UT-2674SM NEW
$100.00
Ex Tax:$100.00
Add to Cart Add to Wish List Compare this Product
10pcs/Lot C65N-DC 1P C10A A9N22404 Miniature Ciruit Breaker New
Quickview
10pcs/Lot C65N-DC 1P C10A A9N22404 Miniature Ciruit Breaker New
$50.00
Ex Tax:$50.00
Add to Cart Add to Wish List Compare this Product
10pcs/Lot C65N-DC 1P C16A A9N22405 Miniature Ciruit Breaker New
Quickview
10pcs/Lot C65N-DC 1P C16A A9N22405 Miniature Ciruit Breaker New
$50.00
Ex Tax:$50.00
Add to Cart Add to Wish List Compare this Product
10pcs/Lot C65N-DC 1P C25A A9N22407 Miniature Ciruit Breaker New
Quickview
10pcs/Lot C65N-DC 1P C25A A9N22407 Miniature Ciruit Breaker New
$60.00
Ex Tax:$60.00
Add to Cart Add to Wish List Compare this Product
10pcs/Lot C65N-DC 2P C10A A9N22424 Miniature Ciruit Breaker New
Quickview
10pcs/Lot C65N-DC 2P C10A A9N22424 Miniature Ciruit Breaker New
$160.00
Ex Tax:$160.00
Add to Cart Add to Wish List Compare this Product
10pcs/Lot C65N-DC 2P C16A A9N22425 Miniature Ciruit Breaker New
Quickview
10pcs/Lot C65N-DC 2P C16A A9N22425 Miniature Ciruit Breaker New
$140.00
Ex Tax:$140.00
Add to Cart Add to Wish List Compare this Product
Tags: PC/104
CB-114 MOXA PC/104 Multiple serial boards 4-port RS-232/422/485 PC/104 + modules

If you need more than 10pcs and want to get better wholesale price, please feel free to contact us by following:
email:[email protected]
Tel:0086-574- 88333153
We will quote you our best price to you in 24hours.

CB-114 MOXA

Features and Benefits

921.6 Kbps maximum baudrate for super fast data transmission

On-chip H/W and S/W flow control

Built-in 15 KV ESD protection

Serial interface is DIP switch selectable

Onboard Tx and Rx LED indicators for each port

Windows (XP/Vista/7), Windows CE 5.0/6.0, and Windows XP embedded operating systems supported

Wide temperature model available for -40 to 85°C environments



Overview

The CB-114 PC/104-Plus module comes with 4 RS-232/422/485 ports, and can be used with PC/104-Plus CPU boards that accept the PC/104-Plus expansion interface. Optional DB9 and DB25 connection cables are available for connecting to serial devices, and the CB-114's versatile driver support makes the module suitable for a wide range of applications. The CB-114 module can be used on the PC/104-Plus (PCI) bus, and provides a reliable, high performance solution for multiport serial communication.



• Hardware

Comm. Controller

MU860 (16C550C compatible)

Bus

PC/104-Plus bus

Connector

40-pin box header

DIP Switches

Serial interface

• Serial Interface

Number of Ports

4

Serial Standards

RS-232/422/485

Max. No. of Boards per PC

4

• Serial Line Protection

ESD Protection

15 KV on the board

• Performance

Baudrate

50 bps to 921.6 Kbps

• Serial Communication Parameters

Data Bits

5, 6, 7, 8

Stop Bits

1, 1.5, 2

Parity

None, Even, Odd, Space, Mark

I/O Address

Assigned by BIOS

IRQ

Assigned by BIOS

FIFO

128 bytes

• Serial Signals

RS-232

TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND

RS-422

TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND

RS-485-4w

TxD+(B), TxD-(A), RxD+(B), RxD-(A), GND

RS-485-2w

Data+(B), Data-(A), GND

• Driver Support

Operating Systems

Windows 9X/ME/NT/2000, Windows XP/2003/Vista/2008/7 x86/x64, Windows CE 5.0/6.0, Windows XP Embedded, DOS, Linux 2.4, Linux 2.6 x86/x64, QNX 6

Note

Please refer to Moxa's website for the latest driver support information.

• Physical Characteristics

Dimensions

90 x 96 mm (3.54 x 3.78 in)

• Environmental Limits

Operating Temperature

Standard Models: 0 to 55°C (32 to 131°F)
Wide Temp. Models: -40 to 85°C (-40 to 185°F)

Storage Temperature

-40 to 85°C (-40 to 185°F)

Ambient Relative Humidity

5 to 95% (non-condensing)

• Standards and Certifications

EMC

CE, FCC

EMI

EN 55022, EN 61000-3-2, EN 61000-3-3, FCC Part 15 Subpart B Class A

EMS

EN 55024, IEC 61000-6-2, IEC 61000-6-4, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11 (DIPS)

Green Product

RoHS, CRoHS, WEEE

• MTBF (mean time between failures)

Time

381,081 hrs

Database

Telcordia (Bellcore), GB

• Power Requirements

Power Consumption

164 mA @ 5 VDC
